Ubjective The objective of this exercise is to further explo

Ubjective: The objective of this exercise is to further explore the usage of digital multimeters (DMM), Upon the completion of this lab, the student will: Distinguish the different parts of the DMM. Use the DMM to measure resistance. Background: As discussed in an earlier lab, a digital multimeter (DMM), can be used to diagnose circuits. But before we can use the DMM, we must learn its different components, specifically the Display the Selection Knob and the Ports. The display shows t typically has three to four digits and the ability to display a negative sign: the reading of the measured quantity and 055 The selection knob allows the user to set the multimeter to read different things such as current (A), voltage (V) and resistance (2):

Solution

1a) No, all the DMM readings will not be lies in min and Max range of nominal values. Because the accuracy or error of DMM depends upon the Full scale range selected.

2A) they do not agree because of accuracy level of DMM.

3A)if we measure the resistance connected in circuit it will shows whole circuit resistance at that terminal across that terminals instead it\'s.(only supply to the circuit is not given.
