A 9 V battery is hooked up to two resistors in series. One has a resistance of 5 and the other has a resistance of 10 . Several locations along the circuit are marked with letters, as shown in the figure. Which statement is true?

Select one: A. The current at A is greater than the current at B, which is equal to the current at C, which is greater than the current at D.

B. The current at A is equal to the current at B, which is equal to the current at C, which is equal to the current at D.

C. The current at A is greater than the current at B, which is greater than the current at C, which is greater than the current at D.

Solution

In series the current is same at all points in the circuit.

So, answer is

The current at A is equal to the current at B, which is equal to the current at C, which is equal to the current at D.
