Given the following two Dflip flops complete the state table

Given the following two D-flip flops, complete the state table.

Solution

D Type Flip-flop gives output 1 when clock enabled and inputs is 1

D Type Flip-flop gives output 0 when clock enabled and input is 0

arrow is in so,clock enabled.so,

A(t)	B(t)	X	A(t+1)	B(t+!)
0	0	0	0	0
0	0	1	0	0
0	1	0	1	0
0	1	1	0	0
1	0	0	0	1
1	0	1	1	0
1	1	0	1	1
1	1	1	1	0
