Explain how limit load factors change with changes in aircra

Explain how limit load factors change with changes in aircraft weight. Support your answer with formula work and/or calculation example.

Solution

Does load factor limit actually change with aircraft weight?

up vote6down votefavorite

Does load factor limit in reality change with aircraft weight? Is it fixed to make certification and operation more simple? Now unloaded aircraft has lower Va speed. This makes sense to keep constant maximum G. But if aircraft can sustain +2.5g at MTOW will anything break if it sustains +3.0g completely empty? As I understand wing bending force will be the same and this should be limiting factor in most aircraft? What else can break? Engines fall off? Tail breaks off? Theoretically possible but can this really happen?

aircraft-performance aircraft-certification

shareimprove this question
asked Feb 2 at 20:10
Andrius
1,350419

add a comment

1 Answer

activeoldestvotes

up vote6down voteaccepted

Yes, the limits are always set by the worst combination of weight, loading, flight speed and expected gust speed. They are valid over the full range of parameters for simplicity reasons.

Note that the load factor limits are not directly proportional to the aircraft\'s overall weight, but theweight of the non-lifting parts. An empty fuselage and full wing tanks allow the aircraft to pull more gs or fly faster until the maximum wing bending moment is reached when flying through the maximum expected gust. Calculating the precise load limit during each stage of a flight would put excessive demands on any pilot and increase the risk of errors.

All components should be sized so that they fail at 150% of calculated maximum loads. In real aircraft some secondary considerations like the availability of sheet metal gauges or extruded profiles put a limit to this local optimization, but technically the chance for breaking is the same for all structural parts. All the failures described in your question have happened in the past when aircraft were overstressed or improperly designed.
