NAND gate designing question
Solution
In PUN:
for only 1 conducting pmos transistor (A or B or C or D or E equal to 0 and Y=1, (W/L)p = 8*1 = 8
for all conducting pmos transistor (A=B=C=D=E=1 and Y=0, (W/L)p = 8*5 = 40
In PDN:
for only 1 conducting nmos transistor (A or B or C or D or E equal to 1 and Y=1, (W/L)n = 4/1 = 4
for all conducting nmos transistor (A=B=C=D=E=1 and Y=0, (W/L)n = 4/5 = 0.8
