Consider an institutional LAN shown in the figure below, that is composed of five hosts (A, B, C, D, and E) and two transparent switches (Switch 1 and Switch 2). Assume that five frames are exchanged between the hosts as follows: A sends to B, D sends to E, E sends to C, B sends to A, and C sends to E. Show the detailed learning process and contents of the switch tables of each of the two switches in each step of the process

Solution

When a Host sends frame to a another host connected to the switch , switch broadcast the frame seeking the mac address of destination address. Destined machine responds with its mac address .

here switch tags the mac address with switch interface in its switching table.This is called learning process so when next time a frame is sent switch wont broadcast it. it will directly sends the frame to destination machine.

Here in this case when A sends to B switch 1 will broadcast seeking mac address of destined host , here B responds with its mac address. there fore switch tags the mac address of A & B with interface 1 & 2 respectively.

similarly when D sends to E , switch S2 broadcast and learns the mac address of D & E from Interface 2 & 3 respectively .

Similarly , when E sends to C switch S2 broadcast it and frmae reaches to S1 where interface 3 of switch 2 responds with its MAC address.

tables on S1 and S2 would be

mac address of E would be tagged on interface 4 on switch S1 and interface 3 on switch S2 , mac address of of C would be tagged with interface 3 on switch S1 and interface 1 on switch S2.

When B sends to A , it will be matched in switching table of S2 and be directly forwarded to A as the interface and mac address of A & B already tagged in switching table.

When C sends to E , frmae will egress through interface 4 of switch S1 and ingress in interface 1 of switch S2 and forwarded to E through Interface 3 since the tagging is already there in switching table .

learning process is one time when switch broadcast the frame , once switch tags/learns the mac address to corresponding interface it maintains the table if it is not cleared the mac table or rebooted.
