Extract information from graph below and solve for power, specific heat capacity, latent heat of fusion, and conservation of energy. Consider the data given in Figure 1 which shows graphically the optimum rates at which lasers of different powers cut through sheets of mild-steel. This figure is rich in qualitative as well as quantitative information. This information can easily be understood if you read the graph in a systematic manner SHEET THICKNESS(m 26810 12 14 400 10 160 120 280 240 O 160 120 1000 80 500 W 0 02 0.3 0.5 0.6 SHEET THICKNESS (in) NGZZLE 0.045 in. 0.051. 0.06\". NCREASING A. RYGEN PRESS 2- DECKEASING PRESSURE Source: J. Powell, CO2 Laser Cutting, to be published in Eng- lish by Carl Hanser Verlag, Munich, F.R.G, in 1990 Figure 1. Cutting speeds for sheets of mild steel using CO2 laser.

Solution

Solution:

1. Optimum cutting speed : From figure 1, for 0.25\" sheet thickness and 1500 W CO₂ laser, optimum cutting speed is approximately 70\"/min.

2. r = 2.5 ft. So, perimeter = 2*3.14157*r= 31.416 ft = 377\".

Light energy delivered = (377/50)*1500*60 =678600 kJ

3. Mass of the metal that melted out = 377\"x2.54x0.2x0.25x2.54x7.86 = 955.87 gm.

4. Energy spent to raise the temperature to the melting point = mCpdT = (955.87/1000)x620x(1515-20) =886 kJ

5. Energy absorbed by the metal surface = 10% of the laser power = 678600x10% = 6786 kJ.

6. Fraction of the laser light spent in raising the temperature of the metal to its melting point & melting it

= 100x886/6786 = 13.06%

7. Energy spent for melting = Latent heat of fusion x mass of the metal = 247 x (955.87/1000) = 236.1 kJ

So, energy dispersed by conduction, convection and radiation = 6786 - (886 + 236.1) = 5664 kJ.

Fraction that dispersed = (5664/6786)x100 = 83.46%

So, the efficiency of the CO₂ laser = 100 - 83.46 = 16.54%.
