view questions 1 of 2 It is suggested that you complete this test at the computer after reproducing Figure 15-1. Circle the best answer. l. The isometric grid is obtained from which ofthe following commands? a. ELEV c, SNAP b. LINE 2. Which of the following is used to toggle from one isoplane to another? a. F3 c Ctrl-T d, Ctrl-P b, F5 3. What happens when the C key is pressed as a response to the prompt: \"Specify next point or IUndoMClosel: a. The rectangle is copied. b. The rectangle is changed to layer C. c. The rectangle is opened. d. The rectangle isclosed. 4. In response to the prompt \"Line: Specify first point:\" which of the follow- ing starts a line from the endpoint of the last line drawn? c, Ctrl-E b, F6 d, REPEAT 5. An ellipse that appears in the following position would have been drawn in the a. Left isoplane c. Top isoplane b. Rights isoplane d. None of the above 6. An ellipse that appears in the following position would have been drawn in the c. Top isoplane b. Right isoplane d. None of the above 7. An ellipse that appears in the following position would have been drawn in the Left isoplane c. Top isoplane b. Right isoplane d. None of the above 8. Which of the following is the same as-30 a. 600 c. 210 b. 150 d. 330 9. Which tab of the Hatch dialog box contains the gradient hatch patterns? a. Gradient b. Hatch d. Shading 10. Which of the following commands is used to move a gradient hatch pat- tern to the back of the drawing stack? a. Move c. Draw Order b. Layer d. Draw Edit Part IbBasic AutoCAD

Solution

1) SNAP COMMAND

2) F5 is used for toggle from one isopalne to another in autocad.

9) Hatch

Fills an enclosed area or selected objects with a hatch pattern, solid fill, or gradient fill10) Move.

13) Polygon
