The structure, shown below, composed of metal bars was considered in class. The temperature of the end of each bar is given in the figure. The temperatures x_1,x_2 and x_3 are the averages of the three adjacent temperatures. The system of equations, Ax =b, was shown in class to be: Use cofactors to find the inverse of the coefficient matrix A. Use A^-1 to solve for x.

Solution

Solution:

A = 3-1-1-13-1-1-13

Find matrix determinant :

det A = 16

Show detailed calculation of the determinant

The determinant of is not zero, therefore the inverse matrix A^-1 exist. To calculate the inverse matrix find additional minors and cofactors of matrix

Find the minor M₁₁ and the cofactor C₁₁. In matrix A cross out row 1 and column 1.

Show detailed calculation of the determinant

C₁₁ = (-1)¹⁺¹M₁₁ = 8

Find the minor M₁₂ and the cofactor C₁₂. In matrix A cross out row 1 and column 2.

Show detailed calculation of the determinant

C₁₂ = (-1)¹⁺²M₁₂ = 4

Find the minor M₁₃ and the cofactor C₁₃. In matrix A cross out row 1 and column 3.

Show detailed calculation of the determinant

C₁₃ = (-1)¹⁺³M₁₃ = 4

Find the minor M₂₁ and the cofactor C₂₁. In matrix A cross out row 2 and column 1.

Show detailed calculation of the determinant

C₂₁ = (-1)²⁺¹M₂₁ = 4

Find the minor M₂₂ and the cofactor C₂₂. In matrix A cross out row 2 and column 2.

Show detailed calculation of the determinant

C₂₂ = (-1)²⁺²M₂₂ = 8

Find the minor M₂₃ and the cofactor C₂₃. In matrix A cross out row 2 and column 3.

Show detailed calculation of the determinant

C₂₃ = (-1)²⁺³M₂₃ = 4

Find the minor M₃₁ and the cofactor C₃₁. In matrix A cross out row 3 and column 1.

Show detailed calculation of the determinant

C₃₁ = (-1)³⁺¹M₃₁ = 4

Find the minor M₃₂ and the cofactor C₃₂. In matrix A cross out row 3 and column 2.

Show detailed calculation of the determinant

C₃₂ = (-1)³⁺²M₃₂ = 4

Find the minor M₃₃ and the cofactor C₃₃. In matrix A cross out row 3 and column 3.

Show detailed calculation of the determinant

C₃₃ = (-1)³⁺³M₃₃ = 8

Write matrix of cofactors:

C = 844484448

Transposed matrix of cofactors:

C^T = 844484448

Find inverse matrix:

A^-1 = C^Tdet A = 121414141214141412

A-1= 1/2 1/4 1/4

1/4 1/2 1/4

1/4 1/4 1/2

B) x(1) = 1/2a + 1/4b+ 1/4c

x(2) = 1/4a + 1/2b + 1/4c

x(3) = 1/4a + 1/4b + 1/4c
