Individual Project through CC with Arduino IDE and Simulate

Individual Project through C/C++ with Arduino IDE and Simulate on Proteous and UNO Board, The purpose of this assignment is to refresh the knowledge of programing and digital logic learn in previous courses.

Design a Firmware that can perform following.

1.   Take input number “A” ranging (0-F) through serial port, store it in a variable and display it on SSD in form of BCD and on LEDs in form of binary.

2.   Take input number “B” ranging (0-F) through serial port, store it in a variable and display it on SSD in form of BCD and on LEDs in form of binary.

3.   Take input mode “M” ranging (0-9) through serial port from user, store it in a variable and display it on SSD.

0.   Addition Result on SSD s only

1.   Subtraction Result on SSD s only

2.   Multiplication Result on SSD s only

3.   AND Result on LEDs only

4.   OR Result on LEDs only

5.   NOT (For input B only) Result on LEDs only

6.   NAND Result on LEDs only

7.   NOR                                            Result on LEDs only

8.   XOR                                            Result on LEDs only

9.   XNOR                                         Result on LEDs only

10. Multiplication Result on LEDs only

Input is to be taken from Serial Port and output is also is to be shown on Serial Port

Solution

[cc lang=‘C’]
void setup()
{
pinMode(13,OUTPUT);
}

void loop()
{
digitalWrite(13,HIGH);
delay(500);
digitalWrite(13,LOW);
delay(500);
}
[/cc]
