Turn in clearly written, well organized solutions. Use one-side of page only. Start each problem on a new page. NO REQUIRED FORMAT Show sketch, given data, basic eqn or definition in symbols, calculated answer with units Warning: The \"hydrostatic equation in Chp 2 is [dp = -rho g dz] Do not start from Delta p = (+/-) rho g h Fluid forces can be expressed as several components or as a single concentrated force. Understand the various forms. The homogeneous gate shown consists of one quarter of a circular cylinder and is used to maintain a water depth of 4 m. That is, when the water depth exceeds 4 m, gate opens slightly and lets the water flow under it. Determine the weight of the gate per meter of length. Approx Wt = 64 kN Also clearly show the values & locations for the horizontal and vertical force components of the fluid force.

Solution

The answer of following questions is as follows.

The weight of following flowing fluid is 65 kn.
