During the configuration design of a special purpose part we modify aspects, i.e. make decisions to develop different alternative configurations. For the steel plate below sketch two alternatives or each aspect of configuration: Type of feature Arrangement Relative dimensions Label

Solution

For the alternative A circular plates with square holes can be a type of feature and the holes can be arranged in column instead in a row. Same thing can be done for alternative B also.
