A reversebiased diode has the connected to the positive side

A reverse-biased diode has the connected to the positive side of the source, and the connected towards the negative side of the source. A) anode, cathode B) cathode, anode C) base, anode D) cathode, base

Solution

Connecting the p-type region to the negative terminal of the battery and the n-type region to the positive terminal corresponds to reverse bias. If a diode is reverse-biased, the voltage at the cathode is comparatively higher than at the anode.

So, the cathode is connected to the positive side and anode connected towards the negative side of the source

Answer is B)
