What are the indices for the directions indicated by the two vectors in the sketch below? Determine indices for the directions shown in the following unit cells: What are the indices for the two planes drawn in the sketch below Below are shown three different crystallographic planes for a unit cel of some hypothetical metal. The circles represent atoms:

Solution

First projection structure

Here the value of direction projections along a1, a2, z axis are 1, 1/2 and 1/2. When multiplied with 2, we get, 2, 1, 1. With u, v, t and w directions for projection of hexagonal,

That is,

u\' = 2

v\' = 1

w\' = 1

Feed values in Hexagonal indices determination equation we get,

u = 1/3(2u\' - v\') = 1/3[2 x 2 - 1] = 1

v = 1/3(2v\' - u\') = 1/3[2 x 1 - 2] = 0

t = -(u + v) = -(1 + 0) = -1

w = w\' = 1

Therefore the directions in the four directions in the four indices scheme becomes, 101\'(with a bar on top for -ve)1

with, 1\' = 1 with a bar on top for -ve

Answer = 101\'1

Second projection structure on right on top

Here the value of a1, a2, z are a/2, a and 0 (or 1/2, 1, 0). When multiplied with 2, we get, 1, 2, 0. With u, v, t and w directions for projection of hexagonal,

That is,

u\' = 1

v\' = 2

w\' = 0

Feed values in Hexagonal indices determination equation we get,

u = 1/3(2u\' - v\') = 1/3[2 x 1 - 2] = 0

v = 1/3(2v\' - u\') = 1/3[2 x 2 - 1] = 1

t = -(u + v) = -(0 + 1) = -1

w = w\' = 0

Therefore the directions in the four directions in the four indices scheme becomes, 011\'(with a bar on top for -ve)0

with, 1\' = 1 with a bar on top for -ve

Answer = 011\'0

First Structure from below row on left

Here the value of directions projection along axis are -1, -1, 1/2. When multiplied with 2, we get, -2, -2, 1. With u, v, t and w directions for projection of hexagonal,

That is,

u\' = -2

v\' = -2

w\' = 1

Feed values in Hexagonal indices determination equation we get,

u = 1/3(2u\' - v\') = 1/3[2 x -2 - (-2)] = -2/3

v = 1/3(2v\' - u\') = 1/3[2 x -2 - (-2)] = -2/3

t = -(u + v) = -(-2/3 - 2/3) = 4/3

w = w\' = 1

Multiply with 3

Therefore the directions in the four directions in the four indices scheme becomes, 2\'2\'(with a bar on top for -ve)43

with, 2\' = 2 with a bar on top for -ve

Answer = 2\'2\'43

First Structure from below row on left

Here the value of directions projection along axis are 0, -1, 0. With u, v, t and w directions for projection of hexagonal,

That is,

u\' = 0

v\' = -1

w\' = 0

Feed values in Hexagonal indices determination equation we get,

u = 1/3(2u\' - v\') = 1/3[2 x 0 - (-1)] = 1/3

v = 1/3(2v\' - u\') = 1/3[2 x -1 - 0] = -2/3

t = -(u + v) = -(1/3 - 2/3) = 1/3

w = w\' = 0

Multiply with 3

Therefore the directions in the four directions in the four indices scheme becomes, 12\'(with a bar on top for -ve)10

with, 2\' = 2 with a bar on top for -ve

Answer = 12\'10
