MATLAB problem Would like detail The pressure drop delta p i

The pressure drop delta p in Pa for a fluid flowing in a pipe with a sudden increase in diameter is given by: delta p = 1/2[1 - (d/D)^2]^2 rho v^2 where rho is the density of the fluid, v, the velocity of the flow, and d and D are defined in the figure. Write a program in a script file that calculates the pressure drop delta p. When the script file is executed it requests the user to input the density in kg/m^3, the velocity in m/s, and values of the non-dimensional ratio d/D as a vector. The program displays the inputted values of rho and v followed by a table with the values of d/D in the first column and the corresponding values of delta p in the second column. Use format g in fprintf () to display the table. Execute the program assuming flow of gasoline (rho = 737 kg/m^3) at v = 5 m/s and the following ratios of diameters. d/D = 0.9, 0.8, 0.7, 0.6, 0.5, 0.4, 0.3.

Solution

prompt = \'enter density in kg/m^3 \';
p = input(prompt);

prompt = \'enter velocity in m/s \';
v = input(prompt);

ratios =[];
cnt = 1;

while 1 %ask the user ratios and when user enters 0 stop

x = input(\'enter ratios and when done enter 0 \');
if(x==0)
break;
end
ratios(cnt)=x;
cnt = cnt+1;

end

deltap=[];

%compute deltap for given ratios and store it in vector deltap

for t = 1:length(ratios)


deltap(t)=0.5*(1-(ratios(t))^2)^2*p*v^2;

end

%convert deltap and ratiso into an array with rows=columns i.e number of
%ratiso and columns=row i.e 1
deltap=reshape(deltap,[length(ratios),1]);
ratios=reshape(ratios,[length(ratios),1]);

%convert deltap and ratios into a table and display it
T=table(deltap,ratios)
