7 Which command will provide information specific to OSPFv3

7. Which command will provide information specific to OSPFv3 and static routes in the routing table? (Points : 2)

       show ip route ospf
       show ip route ospfv3
       show ipv6 route
       show ip route ospf
       show ipv6 route ospf

Question 8.8. A network administrator enters the command ipv6 router ospf 64 in global configuration mode. What is the result of this command? (Points : 2)

       The router will be assigned an autonomous system number of 64.
       The router will be assigned a router ID of 64.
       The reference bandwidth will be set to 64 Mb/s.
       The OSPFv3 process will be assigned an ID of 64.
       Answers A and C are correct.

Question 9.9. Which command should be used in OSPF to provide detailed information about every OSPF-enabled interface? (Points : 2)

       show ip protocols
       show ip ospf neighbor
       show ip ospf
       show running-config
       None of the above

Question 10.10. A router in OSPF router has a data rate of 1.544 Mbps on one of its interfaces. What will the OSPF cost of that link be? (Points : 2)

       110
       44
       48
       120
       64

Question 11.11. R1 is currently the DR router. R2 is currently the BDR router. R3 is currently the DROther. Your IT manager has asked you to make R3 the DR and R2 the BDR. Which answer will achieve that goal? (Points : 2)

       Change the priority number on R3 to be the highest.
       Change the priority on R2 to be the second highest.
       Answers A and B are correct.
       Change the router-ID on R3.
       Shutdown R1, R2, and R3 interfaces and bring them back up in the reverse order.

Question 12.12. (TCO 5) Cisco’s routers use this first to determine router-ID in OSPF. Assume IP addresses are configured on physical and loopback Interfaces are working as expected. (Points : 3)

       Largest loopback IP address
       Largest physical Interface IP address
       Lowest loopback IP address
       Configured Router-ID
       Both A and C are correct.

7. Which command will provide information specific to OSPFv3 and static routes in the routing table? (Points : 2)

       show ip route ospf
       show ip route ospfv3
       show ipv6 route
       show ip route ospf
       show ipv6 route ospf

7. Which command will provide information specific to OSPFv3 and static routes in the routing table?

show ipv6 route ospf is used to find information specific to OSPFv3 routes in routing table.

8. A network administrator enters the command ipv6 router ospf 64 in global configuration mode. What is the result of this command?

The OSPFv3 process will be assigned an ID of 64.

9. Which command should be used in OSPF to provide detailed information about every OSPF-enabled interface?

verify ospf interface settings which provides detailed list of every OSPF enabled interface.

10. A router in OSPF router has a data rate of 1.544 Mbps on one of its interfaces. What will the OSPF cost of that link be?

64. This is the default cost of 1.544 OSPF serial link.

11. R1 is currently the DR router. R2 is currently the BDR router. R3 is currently the DROther. Your IT manager has asked you to make R3 the DR and R2 the BDR. Which answer will achieve that goal?

Change the priority number on R3 to be the highest. And then change the priority of R2 to be the second highest. The highest priority wins the DR, and the next highest priority will win the BDR. So, changing R3 to highest priority will make it DR, and R2 will become the BDR.
