I need help creating an Android app which uses Fragments and

I need help creating an Android app which uses Fragments and Transaction Manager such that it will be able to pass data from one fragment to another. I have created the xmls so that Main Activity just displays FragmentTwo which has two ImageButtons that one clicks and based on what he clicks will display a message on FragmentOne. Here are the files so far:

activity_main.xml###################################################################

FragmentTwo.java###################################################################

fragment_two.xml###########################################################################

FragmentOne.java#############################################################

fragment_one.xml ######################################################################################

AndroidManifest.xml##################################################################

###############################################################

Solution

//main.xml <?xml version=\"1.0\" encoding=\"utf-8\"?>
<LinearLayout xmlns:android=\"http://schemas.android.com/apk/res/android\"
    xmlns:tools=\"http://schemas.android.com/tools\"
    android:layout_width=\"match_parent\"
    android:layout_height=\"match_parent\"
    android:orientation=\"vertical\" >
    <Button
        android:id=\"@+id/button1\"
        android:layout_width=\"fill_parent\"
        android:layout_height=\"wrap_content\"
        android:text=\"@string/btn_label1\"/>
    <Button
        android:id=\"@+id/button2\"
        android:layout_width=\"fill_parent\"
        android:layout_height=\"wrap_content\"
        android:text=\"@string/btn_label2\"/>
    <fragment
        android:layout_width=\"match_parent\"
        android:layout_height=\"match_parent\"
        class=\"com.concretepage.android.FragmentOne\"
        android:id=\"@+id/output\"/>
</LinearLayout>

//fragment_one.xml   <?xml version=\"1.0\" encoding=\"utf-8\"?>
<LinearLayout xmlns:android=\"http://schemas.android.com/apk/res/android\"
    android:orientation=\"vertical\"
    android:layout_width=\"match_parent\"
    android:gravity=\"center\"
    android:background=\"#FF0000\"
    android:layout_height=\"match_parent\">
    <TextView
        android:layout_width=\"wrap_content\"
        android:layout_height=\"wrap_content\"
        android:layout_gravity=\"center\"
        android:textColor=\"#b0b0ff\"
        android:textSize=\"20sp\"
        android:id=\"@+id/msg1\"/>
</LinearLayout>

//fragment_two.xml    <?xml version=\"1.0\" encoding=\"utf-8\"?>
<LinearLayout xmlns:android=\"http://schemas.android.com/apk/res/android\"
    android:orientation=\"vertical\"
    android:layout_width=\"match_parent\"
    android:gravity=\"center\"
    android:background=\"#b0b0ff\"
    android:layout_height=\"match_parent\">
    <TextView
        android:layout_width=\"wrap_content\"
        android:layout_height=\"wrap_content\"
        android:layout_gravity=\"center\"
        android:textColor=\"#FF0000\"
        android:textSize=\"20sp\"
        android:id=\"@+id/msg2\"/>
</LinearLayout>

//strings.xml <?xml version=\"1.0\" encoding=\"utf-8\"?>
<resources>
    <string name=\"app_name\">Concrete Page</string>
    <string name=\"btn_label1\"> Fragment One </string>
    <string name=\"btn_label2\"> Fragment Two </string>
</resources>

//Activity & Fragment Implementations //FragmentOne.java

package com.concretepage.android;
import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;
import com.cp.android.R;
public class FragmentOne extends Fragment {
    @Override
    public View onCreateView(LayoutInflater inflater,ViewGroup viewGroup, Bundle savedInstanceState) {
        View view = inflater.inflate(R.layout.fragment_one, viewGroup, false);
        TextView output= (TextView)view.findViewById(R.id.msg1);
        output.setText(\"Fragment One\");
        return view;
    }
}

//FragmentTwo.java

package com.concretepage.android;
import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;
import com.cp.android.R;
public class FragmentTwo extends Fragment {
    @Override
    public View onCreateView(LayoutInflater inflater,ViewGroup viewGroup, Bundle savedInstanceState) {
        View view = inflater.inflate(R.layout.fragment_two, viewGroup, false);
        TextView output= (TextView)view.findViewById(R.id.msg2);
        output.setText(\"Fragment Two\");
        return view;
    }
}

//MainActivity.java

package com.concretepage.android;
import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentActivity;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentTransaction;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.Button;
import com.cp.android.R;
public class MainActivity extends FragmentActivity{
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);
        OnClickListener listener = new OnClickListener() {
       public void onClick(View view) {
           Fragment fragment = null;
           if(view == findViewById(R.id.button1)){
                      fragment = new FragmentOne();
           } else {
                      fragment = new FragmentTwo();
           }
                        FragmentManager manager = getSupportFragmentManager();
                        FragmentTransaction transaction = manager.beginTransaction();
                        transaction.replace(R.id.output, fragment);
                        transaction.commit();
       }
         };
        Button btn1 = (Button)findViewById(R.id.button1);
        btn1.setOnClickListener(listener);
        Button btn2 = (Button)findViewById(R.id.button2);
        btn2.setOnClickListener(listener);
    }
}

// AndroidManifest.xml <?xml version=\"1.0\" encoding=\"utf-8\"?>
<manifest xmlns:android=\"http://schemas.android.com/apk/res/android\"
    package=\"com.cp.android\"
    android:versionCode=\"1\"
    android:versionName=\"1.0\" >
    <uses-sdk android:minSdkVersion=\"11\" />
    <application
        android:allowBackup =\"false\"
        android:icon=\"@drawable/ic_launcher\"
        android:label=\"@string/app_name\" >
        <activity
            android:name=\"com.concretepage.android.MainActivity\"
            android:label=\"@string/app_name\" >
            <intent-filter>
                <action android:name=\"android.intent.action.MAIN\" />
                <category android:name=\"android.intent.category.LAUNCHER\" />
            </intent-filter>
        </activity>
    </application>
</manifest>

Output :
