The following diagram represents a normal wild-type chromosome. below this diagram is the same chromosome in which a chromosomal mutation has occurred..

De following diagram represents a normal wild-type chromosome. Below this diagram is the same Cnromosome in which a chromosomal has Place the type of chromosomal mutation next to each set of chromosomes. The represents the centromere. Wild-type Chromosome A B. C D EFG al Mutation 1 Tandem duplication of DEF A B. C DEF DEF G Paracentric inversion that includes DEFG Displaced duplication of DEF Deletion of FG Chromsomal Mutation 2 Pericentric inversion of BCDE A B. DEF C DEFG Displaced duplication of DEF Paracentric inversion that includes DEFG Chromsomal Mutation 3 Deletion of FG A B. C D E Chromsomal Mutation 4 A, B. C G FED Paracentric inversion that includes DEFG Chromsomal Mutation 5 Pericentric inversion of BCDE A EDC. BFG

Solution

mutation1

AB CDEFDEFG - Tandem duplication DEF as DEF is repeated next to the coresponding sequence.

mutation2

AB DEFCDEFG - displaced duplication of DEF, as DEF is duplicaed at region other than next to the the corresponding sequence.

mutation3

AB CDE - Deletion of FG

mutation4

AB CGFED- paracentric inversion tha includes DEFG as it doesnot incolve centromere

mutation5

AEDC BFG- pericentric inversion of BCDE as it involves centromere also.
