Assembly Language Problem

Please don\'t forget to draw a memory map and specify values of all labels used. Thanks in advance :)

Draw a memory map diagram illustrating the contents of all memory affected by the following block of 68K code. Also specify the values of all labels used. ORG $600 PEAR DC.B 5, 8, 24 APPLE DC.W 6, 12, 35 KIWI DC.L 13 DS.B 2 MANGO EQU $1E GRAPE DC.W 2, MANGO ORANGE DC.L KIWI MANGO

Solution

PEAR 600

APPLE 603

KIWI 604

0000

MANGO 1E

GRAPE 606 MANGO value given to dc.w ie grape 4 BYTES

ORANGE 13+1E
