Please draw a free body diagram of this margarita mixer assembaly showing torque, power, moments, etc. along with equations. Horse power:.25
S340, 341, 342 Beater D Beater Door Assembly (Standard Door/No Door/No Prime Plug) 341, 342 Pri 13 11 19 9 8 5 Solution
Free body diagram is a diagram showing the forces and reactions acting on a system after removing all the supports and end constraints. The image shown is different.
According to the given figure Horse power is given as 25 which is the power provided by the motor to the mixer shaft.
Torque is given by T= P×60/2×3.14×N
