Which section is used to eliminate aliasing effects D Low P

Which section is used to eliminate aliasing effects? D - Low Pass Filter F-High Pass Filter C - Input Buffer H - Microprocessor Which section gives correction for residual offset voltages? H - Microprocessor D - Low Pass Filter A - Human Body F-High Pass Filter Which section can be used for feature extraction? A - Human Body F-High Pass Filter G-A/D Converter H - Microprocessor Which section would represent output by the system state machines K-Wireless Comm B - Multiplexer H - Microprocessor F-High Pass Filter If the system is sampled at 200 Hz, what is the Nyquist frequency of the system? 50 Hz 100 Hz 200 Hz 400 Hz

Solution

Q-6. D-Low Pass Filter

Q-10. Answer:b) 100 Hz

Nyquist frequency = (1/2)V

=1/2(200) = 100 Hz
