Please answer question two. Thank you.

1) The following shows two threads, Thread A and Thread B, to be run on superscalar machine with 2 slots. Assume that before the code is run a, b, x and y are 0. Show how each would execute on Fine-Grained Multithreading. What are values of a, b, x and y at the end of Fine MT completion? Thread A Time Thread B Al A2 B1 182 A3 3 A4 B3 B4 ASA A7 A2: a b+7 B2: x at y A4: a Exty a +7 A5: xt-5 A6: as y+7 A7: bay b

Solution

a) core 1 scheduled first followed by core 2

Thread A:

A1: x = y+5 , x=5

A2: a = b+7 , a = 7

A3: y = x*a, y = 35

A4: a= x+y, a = 40

A5: x +=5 , x = 10

A6: a = y+7 , a = 42

A7: b = y+b , b = 35

Core 2, Thread B

B1: a = y+3 , a = 38

B2: x = a+y, x = 77

B3: x = b+7, x = 42

B4: y = a+7, y=45

b) core 2 scheduled first followed by core 1

Core 2, Thread B

B1: a = y+3 , a = 3

B2: x = a+y, x = 3

B3: x = b+7, x = 7

B4: y = a+7, y=10

Thread A:

A1: x = y+5 , x= 15

A2: a = b+7 , a = 7

A3: y = x*a, y = 105

A4: a= x+y, a = 120

A5: x +=5 , x = 20

A6: a = y+7 , a = 112

A7: b = y+b , b = 105
