what combination of input levels should you apply to the gate\'s inputs to determine which type of gate it is?

Solution

Que : what combination of input levels should you apply to the gate\'s inputs to determine which type of gate it is ?

Ans :
       let say the inputs are A and B.
let look at the truth tables for AND and OR gate

type A B AND OR
----- -- -- --- ---
1 0 0 0 0
   2       1 0 0 1
   3       0 1 0 1
   4       1 1 1 1

   Combination to be tested will be -- type4 ,type3, type2

type3 type4 type2 gate
---- --- ---- ---
1 0 AND
1 1 OR
0 1 1 XOR

For gate to be identified as AND or OR gate , type2 output will not matter.
