A 2-to-4 decoder has inputs A1–A0 and outputs Y0–Y3. What is the Boolean equation for the Y2 output?

Answer:

Boolean expression of Y2 :

Y2=(A0)\' A1

We know that output would be like this : 00,01,10,11

Y2 corresponds to 10 .

So A1 in original form and A0 in negated form.
