Project through CC with Arduino IDE and Simulate on Proteous

Project through C/C++ with Arduino IDE and Simulate on Proteous and UNO Board. Design a Firmware that can perform following.

1. Take input number “A” ranging (0-F) through serial port, store it in a variable and display it on SSD in form of BCD and on LEDs in form of binary.

2. Take input number “B” ranging (0-F) through serial port, store it in a variable and display it on SSD in form of BCD and on LEDs in form of binary.

3. Take input mode “M” ranging (0-9) through serial port from user, store it in a variable and display it on SSD.

0. Addition Result on SSD s only

1. Subtraction Result on SSD s only

2. Multiplication Result on SSD s only

3. AND Result on LEDs only

4. OR Result on LEDs only

5. NOT (For input B only) Result on LEDs only

6. NAND Result on LEDs only

7. NOR Result on LEDs only

8. XOR Result on LEDs only

9. XNOR Result on LEDs only

10. Multiplication Result on LEDs only

Input is to be taken from Serial Port and output is also is to be shown on Serial Port

Need Code for every operation invidually all the above 10 operations....

Solution

Recreation is an effective device to see how the gadget will function in the wake of executing in real.Before begin any venture, it is a decent practice to reenact it and basically check that works. Proteus is a reproduction base software.By utilizing this product Arduino can be simulate.Today we will mimic arduino in Proteus. We will test arduino Blink program with Proteus.Lets do it.
