An engine takes 3.25 mole of an ideal monatomic He gas through the cycle shown in the figure. Note that the temperature of the gas does not change during process c-a. Find the pressure at point a. Find the temperature at points a, b, and c. How much heat went in or out of the gas during segments a-b, b-c, and c-a? In each case explain whether heat entered or left the gas.

Solution

Here an Isothermal process [T remains constant], Studying the graph

At point C ; V=0.040m³, P= 2*10⁵ pa, n=3.5 moles

Using the ideal gas law, PV= nRT

we get T= pV/nR= 2*10⁵ *0.040 /3.5 * 8.314= 275 K

a] Pressure at point a is P_a= nRT/ V_a= 3.5 * 8.314*275 K / 0.010= 8*10⁵ pa

b] Since it is an Isothermal process, Temperature remains constant throughout the process. Hence tempertaure at point a, b and c is Ta=Tb=Tc= 275 K

c] In segment a- b

W_ab= [PV]_a- [PV]_b= (8*10⁵*0.01) - (8*10⁵*0.04) = 8000-32000= -24000 J [heat flows outward]

In segment b- c

W_bc= [PV]_b- [PV]_c= (8*10⁵*0.04) - (2*10⁵*0.04) = 32000-8000= 24000 J [heat flows inward]

In segment c- a

W_ca= [PV]_c- [PV]_a= (2*10⁵*0.04) - (8*10⁵*0.01) = 8000-8000= 0 J [ No heat flow]
