When satellites observe the Earth, they can scan only part of theEarth\'s surface. Some satellites have sensors that can measure theangle ? shown in the figure. Let hrepresent the satellite\'s distance from the Earth\'s surface and letr represent Earth\'s radius.
Find the rate at which h is changing with respect to? when ? = 30
Find the rate at which h is changing with respect to? when ? = 30
Solution
imagine a circle From centre of earth(O) the satellite is at a distance r+h (A) From centre to the point on earth up to the point where satellite can scan the distance is r (radius of earth) (point B) in triangle OAB angle B is 90 OA = r+h OB = r angle OAB = ? sin (?) = opp side /hyp = r/(r+h) csc (?) = (r+h)/r csc (?) = 1 + h/r csc( ?) - 1 = h/r h = r(csc( ?) - 1 ) dh/d? = -r csc (? )cot( ?) = - 3960 csc 30 cot 30 = --13717.84
