Please show how you did this problem. The table will be provided.

x wewentwin-call of Dut x C Chegg study IGuided sc x MC Please Show Work on H x oads/HW2%20 Apps k12.prnsper-isd.net honkmarks For quick acress place ynur honkmarks here on the honkmarks bar. Import honkmarks nnw ENGR:2760 Design for Manufacturing 3. You want to design a shaft and a pinion gear for a small motor drive. The shaft has an outer diameter of 15mm, and a length of 100mm. The gear has a pitch diameter of 30mm, outside diameter of 33, root diameter of 25, and the bore diameter of 15mm. For a moderately tight and firm connection between the two parts, you want to implement a press fit specified by G7p6. Based on the table provided in the lecture slide, \"ENGR2760 L04 Fits and Tolerances pdf, page 22, determine the relevant tolerance values. 950 AM

Solution

Shaft OD dimension 15mm p6 tolerance means =15.018mm to 15.029 mm

and Gear bore diameter 15 mmG7= 15.006 mm to 15.0024 mm
