For x 110010 of type BITVECTOR5 DOWNTO 0 determine the valu

For x = \"110010\", of type BIT_VECTOR(5 DOWNTO 0), determine the values of the shift operations listed in the column on the left below.

Solution

Solution:

With reference from google .. I got the complete question

a)x SLL 3 = \"010000\"

b)x SLA -2= \"111100\"

c)x SRA 2 = \"111100\"

d)x ROL 1= \"100101\"

e)x ROR -3 = \"010110\"

here are the answers for your question:

a)x(2 DOWNTO 0) & \"000\";

b) x(5) & x(5) & x(5 DOWNTO 2);

c) x(5) & x(5) & x(5 DOWNTO 2);

d) x(4 DOWNTO 0) & x(5);

e)x(2 DOWNTO 0) & x(5 DOWNTO 3);
