Must be done in Java using Netbeans Here are the necessary f

Must be done in Java using Netbeans. Here are the necessary files: https://www.mediafire.com/?llhfi4wxywh2wnn

Tasks and Rubric

Activity

PostgreSQL database install

Follow the instructions in document PostgreSQL_Install.docx

PostgreSQL database restore

Follow the instructions in document PostgreSQL_Runtime.docx

PostgreSQL database connection to Java

Follow the instructions in document Java_ConnectTo_PostgreSQL.docx

Database project

Create a new Java Application project named Database

allowing Netbeans IDE to create the main class called Database

Database.java

Download properties.xml from assignment folder on Webcourses.

Create an instance of class XmlParser, passing “inputOutput/properties.xml” as an argument to the constructor

Declare a variable of class ConnectionData; instantiate it by setting it equal to the return variable from class XmlParser method getConnectionData()

Create an instance of class PostgreSQLConnect by passing the variable of class ConnectionData as an argument to the constructor

Call method getConnection() using the reference variable created above

PostgreSQLConnect.java

Include member variable Connection connect

Write a constructor to receive a parameter of class ConnectionData

Call static method Class.forName() passing argument getType() method call on the instance of ConnectionData

Method call toString() on class instance ConnectionData

Method call getLogin() on class instance ConnectionData

Method call getPassword() on class instance ConnectionData

catch exception type Exception

output to the user that the database connection was not successful

If the code gets past the try/catch without throwing an exception then the database connection was successful, output to the user that the connection was successful

inputOutput package

Create package inputOutput; copy at the directory structure the properties.xml file downloaded from Webcourses

ConnectionData.java

Create class ConnectionData in package inputOutput; it should do the following:

String type

String url

String ipaddress

String port

String database

String login

String password

Getters/setters for member variables

Method toString() should concatenate member variables url, ipaddress, port, and database so that it is in the format \"jdbc:postgresql://localhost:5432/dvdrental\"

XmlParser.java

Create class XmlParser in package inputOutput; it should do the following:

ConnectionData connectionData

Document document

Getter for member variable connectionData

Defined one parameter of type String storing the name of the XML file to parse

Call method parseXmlFile() passing the parameter as an argument

return type void

Define one parameter of type String storing the name of the XML file to parse

Create an instance of class DocumentBuilderFactory

Create an instance of class DocumentBuilder

Instantiate member variable document to the parse method of class DocumentBuilder passing argument ClassLoader.getSystemResourceAsStream() passing the parameter for method parseXmlFile as an argument

Create an instance of class NodeList, instantiate it with method getDocumentElement().getChildNodes() from member variable document

Loop through the length of the NodeList instance

i.Create an instance of class Node, instantiate it to method item() of instance NodeList

ii.Get each element from XML element <driver>

iii.Instantiate member variable connectionData setting each of its member variables relative to the elements in the properties.xml file

properties.xml

Put file in the inputOutput package

Database application

Test Case 1

Test Case 1 passes

Test Case 2

Test Case 2 passes

Source compiles with no errors

Source runs with no errors

Source includes comments

Total

Perform the following test cases

Test Cases

Action

Expected outcome

Test Case 1

Parse XML file

File was successfully parsed

Test Case 2

Connect to database dvdrental

Database connection was successful using properties.xml file data

Activity
PostgreSQL database install	Follow the instructions in document PostgreSQL_Install.docx
PostgreSQL database restore	Follow the instructions in document PostgreSQL_Runtime.docx
PostgreSQL database connection to Java	Follow the instructions in document Java_ConnectTo_PostgreSQL.docx
Database project	Create a new Java Application project named Database allowing Netbeans IDE to create the main class called Database
Database.java	Download properties.xml from assignment folder on Webcourses. Create an instance of class XmlParser, passing “inputOutput/properties.xml” as an argument to the constructor Declare a variable of class ConnectionData; instantiate it by setting it equal to the return variable from class XmlParser method getConnectionData() Create an instance of class PostgreSQLConnect by passing the variable of class ConnectionData as an argument to the constructor Call method getConnection() using the reference variable created above
PostgreSQLConnect.java	Include member variable Connection connect Write a constructor to receive a parameter of class ConnectionData Inside a try block Call static method Class.forName() passing argument getType() method call on the instance of ConnectionData Set variable connect equal to static method call DriverManager.getConnection() passing the following arguments Method call toString() on class instance ConnectionData Method call getLogin() on class instance ConnectionData Method call getPassword() on class instance ConnectionData Inside catch block catch exception type Exception output to the user that the database connection was not successful If the code gets past the try/catch without throwing an exception then the database connection was successful, output to the user that the connection was successful
inputOutput package	Create package inputOutput; copy at the directory structure the properties.xml file downloaded from Webcourses
ConnectionData.java	Create class ConnectionData in package inputOutput; it should do the following: Member variable String type String url String ipaddress String port String database String login String password Getters/setters for member variables Method toString() should concatenate member variables url, ipaddress, port, and database so that it is in the format \"jdbc:postgresql://localhost:5432/dvdrental\"
XmlParser.java	Create class XmlParser in package inputOutput; it should do the following: Member variable ConnectionData connectionData Document document Getter for member variable connectionData Constructor should do the following: Defined one parameter of type String storing the name of the XML file to parse Call method parseXmlFile() passing the parameter as an argument Method parseXmlFile() should do the following: return type void Define one parameter of type String storing the name of the XML file to parse Create an instance of class DocumentBuilderFactory Create an instance of class DocumentBuilder Instantiate member variable document to the parse method of class DocumentBuilder passing argument ClassLoader.getSystemResourceAsStream() passing the parameter for method parseXmlFile as an argument Create an instance of class NodeList, instantiate it with method getDocumentElement().getChildNodes() from member variable document Loop through the length of the NodeList instance i.Create an instance of class Node, instantiate it to method item() of instance NodeList ii.Get each element from XML element <driver> iii.Instantiate member variable connectionData setting each of its member variables relative to the elements in the properties.xml file
properties.xml	Put file in the inputOutput package
Database application
Test Case 1	Test Case 1 passes
Test Case 2	Test Case 2 passes
	Source compiles with no errors
	Source runs with no errors
	Source includes comments
Total

Solution

Database.java

import inputOutput.ConnectionData;
import inputOutput.XmlParser;
public class Database {
   public static void main(String[] args) {
       XmlParser parser = new XmlParser(\"src/inputOutput/properties.xml\");
       parser.parseXml();
       ConnectionData connectionData = parser.getConnectionData();
       PostgreSQLConnect postgreSQLConnect = new PostgreSQLConnect(connectionData);
       postgreSQLConnect.getConnection();
   }
}

ConnectionData.java

package inputOutput;

public class ConnectionData {
   String type;
   String url;
   String ipaddress;
   String port;
   String database;
   String login;
   String password;
   public String getType() {
       return type;
   }
   public void setType(String type) {
       this.type = type;
   }
   public String getUrl() {
       return url;
   }
   public void setUrl(String url) {
       this.url = url;
   }
   public String getIpaddress() {
       return ipaddress;
   }
   public void setIpaddress(String ipaddress) {
       this.ipaddress = ipaddress;
   }
   public String getPort() {
       return port;
   }
   public void setPort(String port) {
       this.port = port;
   }
   public String getDatabase() {
       return database;
   }
   public void setDatabase(String database) {
       this.database = database;
   }
   public String getLogin() {
       return login;
   }
   public void setLogin(String login) {
       this.login = login;
   }
   public String getPassword() {
       return password;
   }
   public void setPassword(String password) {
       this.password = password;
   }

   public String toString() {
       return url+\"://\"+ipaddress+\":\"+port+\"/\"+database;
   }

}

XmlParser.java

package inputOutput;

import java.io.File;

import javax.xml.parsers.DocumentBuilder;
import javax.xml.parsers.DocumentBuilderFactory;

import org.w3c.dom.Document;
import org.w3c.dom.Element;
import org.w3c.dom.Node;
import org.w3c.dom.NodeList;

public class XmlParser {
   ConnectionData connectionData;
   String fileName;
   public XmlParser(String fileName) {
       super();
       this.fileName = fileName;
   }
   public ConnectionData getConnectionData() {
       return connectionData;
   }

   public void parseXml(){
   try {
   File inputFile = new File(fileName);//\"src/inputOutput/properties.xml\");
   connectionData = new ConnectionData();
   DocumentBuilderFactory dbFactory = DocumentBuilderFactory.newInstance();
   DocumentBuilder dBuilder = dbFactory.newDocumentBuilder();
   Document doc = dBuilder.parse(inputFile);
   doc.getDocumentElement().normalize();
   NodeList nListroot = doc.getElementsByTagName(\"properties\");
   for(int temp1 = 0; temp1 < nListroot.getLength(); temp1++){
   Node nNode1 = nListroot.item(temp1);
if (nNode1.getNodeType() == Node.ELEMENT_NODE) {
       Element eElement1 = (Element) nNode1;
       }
   }
   NodeList nList = doc.getElementsByTagName(\"driver\");


   for (int temp = 0; temp < nList.getLength(); temp++) {
          Node nNode = nList.item(temp);
          if (nNode.getNodeType() == Node.ELEMENT_NODE) {
              Element eElement = (Element) nNode;
              String type = eElement.getAttribute(\"type\");
          connectionData.setType(type);
              connectionData.setUrl(eElement.getElementsByTagName(\"url\").item(0).getTextContent());
              connectionData.setIpaddress(eElement.getElementsByTagName(\"ipaddress\").item(0).getTextContent());
              connectionData.setPort(eElement.getElementsByTagName(\"port\").item(0).getTextContent());
              connectionData.setDatabase(eElement.getElementsByTagName(\"database\").item(0).getTextContent());
              connectionData.setLogin(eElement.getElementsByTagName(\"login\").item(0).getTextContent());
              connectionData.setPassword(eElement.getElementsByTagName(\"password\").item(0).getTextContent());
          }
      }
   } catch (Exception e) {
   e.printStackTrace();
   }
   }
   }

PostgreSQLConnect.java

import java.sql.Connection;
import java.sql.DriverManager;

import inputOutput.ConnectionData;

public class PostgreSQLConnect {
ConnectionData connectionData;

public PostgreSQLConnect(ConnectionData connectionData) {
       this.connectionData = connectionData;
}

public Connection getConnection(){
   Connection connection= null;
   try{
       Class.forName(connectionData.getType());
       connection = DriverManager.getConnection(connectionData.toString(),connectionData.getLogin(),connectionData.getPassword());
       System.out.println(\"Connection was successfull\");
   }catch(Exception e){
       e.printStackTrace();
       System.out.println(\"Connection was not successfull\");
   }
   return connection;
}
}
