Help is appreciated!

The flowchart below includes two conditional tests and a subroutine. Create a new flowchart that defines how the program that executes this flowchart would be implemented within \"linear\" code, i.e. all actions must flow in a line with unconditional branches added as needed to achieve proper operation. You may assume the subroutine function will appear after the main loop. determine what value will be in R1 when the program exits. You may find it valuable to track R0 and R1 values through each loop until the code exits.

Solution

If R1 value is greater than 5 then the program will exits. For example in third loop (after starting the program ) R1 value is 6 in this case the respective program will be exit.
