To construct a register file containing eight 16bit register

To construct a register file containing eight 16-bit registers, two input ports and three output ports, we use w number of 16-bit registers with parallel load input, x number of y-to-1 z-bit multiplexers, and p number of q-to-r decoders with enable. Specify the values of w, x, y, z, p, q, and r.

Solution

To construct a register file containing 8 16-bit registers, 2 input port and three output ports, we use w 16-bit registers with parallel load input,x y-to-1 z-bit muxes, andp q-to-r decoder with enable. Specify the values ofw,x,y,z,p,q, andr.

ANS:

W = 8

x = 3

y = 8

z= 16

p=2

q=3

r=8
