Fill in the blanks for the source and destination IP address

Fill in the blanks for the source and destination IP addresses, as well as the source and destination MAC addresses, for a frame traveling from Station A to Station B in the network shown in the following figure.

Solution

For station A :-

Source MAC:- 00:50:12:FB:76:C9

Destination MAC:- 00:10:41:16:FE:24

Source IP:- 131.204.1.2

Destination IP:- 131.204.1.3

For Station B:-

Source MAC:- 00:10:41:16:FE:24

Destination MAC:- 00:50:12:FB:76:C9

Source IP:- 131.204.1.3

Destination IP:- 131.204.1.2
