Which of the plots shown below is the Bode plot for the new

Which of the plots shown below is the Bode plot for the new system.

Please show your work/explain on how to got the answer.

Solution

optionD

since a pole at 100 is introduced i.e, +20db change occurs at 100rad/sec in graph of mod of h(jw)

and from 1000rad/sec there is an decrease of 20db/decade i.e,-20db from 20db gives 0db/decade so D satifies the relation.

Which of the plots shown below is the Bode plot for the new system. Please show your work/explain on how to got the answer.SolutionoptionD since a pole at 100 i
