1.It is an agricultural district with a population of about 3,000,000. Using the information that you learned in Chapter 1, describe the supply system they have (use about 100-200 words). This is a color map-it will be easier to read on a computer than if you print it out B&W.; Terms: Chowk marketplace (white circle) Mohalla -neighborhood Tubewell-groundwater well (rectangles on map) OHR over head reservoir, i.e., water tower (circles on map TM- trunk main ML main line (secondary main) Minor= small canal

Solution

The supply distribution for given area in the map is depicting a \"Dead End System\".

Since the feeder canal is the main source for the given area , which is supplying water through mains, then its is being delivering to the other branches and sub-mains. There is some locations in which tubewell is the source of water supply, The overhead water tank is delivering water to the supply system.

This dead end system is relatively cheap to other distribution systems. The determination of discharges and pressure is easier due to less number of valves. But due to many dead end, the stagnation of water occurs in the pipes.
