F AC B Please solve this functon using the VHDL software u

F = A\'C\' + B

Please solve this functon using the VHDL software using AND, OR gates and provide me with the VHDL code. Please show the timing diagram. use this website https://www.edaplayground.com/

Solution

entity boolfun is

port(A,B,C: in bit; F: out bit);

end entity boolfun;

architecture expboolfun of boolfun is

begin

F=(not(A) and not(C)) or B

End architecture expboolfun;
