Assume that each SRAM\'s address is connected to ADR[15.1] and that its R/W signal is directly connected to the array R/W input. The SRAM\'s chip select input are driven from the array inputs as shown below. If the array is signaled to perform a read at address 40F5_16, which SRAM device(s) will be enabled? Select one or more. ![Assume that each SRAM\'s address is connected to ADR[15.1] and that its R/W signal is directly connected to the array R/W input. The SRAM\'s chip select input](/WebImages/3/assume-that-each-srams-address-is-connected-to-adr151-and-th-971813-1761499660-0.webp "Assume that each SRAM\'s address is connected to ADR[15.1] and that its R/W signal is directly connected to the array R/W input. The SRAM\'s chip select input")
Solution
C) SRAM 2
