RESULT. CONCLUSION: What DO you 34401A DMM C D R2 board Circit with Agdent DMM Figure 3 Network 2.3.2.2 OBJECTIVE:to construct a circuit tor analyge haralle ons of resistors

Solution

Connect the ohmmeter between C and D terminals.

Finally it will be the parallel combination of (R1+R3) and (R2+R4).

RCD =(R1+R3)(R2+R4)/(R1+R3)+(R2+R4)
