In figure 7.17 and 7.18 I have a problem of understanding how I decide the directions of forces P1\', P1\'\', P2\', P2\'\'... that is, how do I know for example that the force P2\'\' is \"to the right\" of bolt 2 and not mirrored about the line G-2? Also, how do I know that forces P1\',... are in the upward direction and not downward?

EDIT:

I suddenly realized, right after I posted that these forces tend to oppose the direction of external force and moment of P. Case closed!
