The Mollier diagram (enthalpy vs entropy) below shows a turbine expansion process in a steam power plant. Which distance represents the actual work delivered by the turbine per unit mass of steam flowing through the turbine? (circle the letter on the chart below).

Solution

1-2s represents ideal work

1-2 represents actual work
