A straight-through cable is created using the 568B standard. Which of the following correctly describes the color-coded cable layout within the connector (from left to right, with the tab down)?

A. White-green, green, white-orange, blue, white-blue, orange, white-brown, brown

B. White-green, green, white-blue, blue, white-orange, orange, white-brown, brown

C. White-orange, orange, white-green, blue, white-blue, green, white-brown, brown

D. White-orange, orange, white-blue, blue, white-green, green, white-brown, brown

Solution

C is correct. This represents the correct pinout for an RJ45 connector using 568B.

A, B, and D are incorrect because these choices do not represent the correct color-coded pinouts.
