Find the currents in the circuit shown.

Solution

Let the current in top is \"i\" and the current in middle is i \' and bottomis i \"

Apply kirchoff\'s second law to upper loop you get ,

12 = 10 i \' + 5 i + 20 i

12= 10 i \' + 25 i       --------( 1)

Apply kirchoff\'s second la to bottom loop you get ,

6 = 5 i \" -10 i \'       -----------( 2)

But from kirchoff\'s first law , i = i \' + i \"

                                        i \" = i - i \'

Substitute this in equation(2) you get,

6 = 5(i-i\') -10 i \'

   = 5 i -5 i \' -10 i \'

6 = 5 i -15 i \'           -----------( 3)

From equation (2) , 12= 25 i +10 i \' ----------( 4)

equation(4) -(equation(3) x5) ==>

12 -(6x5) = 25 i +10 i \' -5(5i-15i\')

     12 -30 = 25 i +10 i\' -25 i +75 i \'

                 = 85 i \'

           -18 = 85 i \'

               i \' = -0.2117 A

Substitute i \' value in equation(3) you get ,

6 = 5 i -15(-0.2117)

   = 5 i + 3.176

5i = 2.823

i = 0.564 A

Therefore i \" = i - i\'

                   = 0.564A-(-0.2117 A)

                   = 0.564A+0.2117 A

                   = 0.7764 A
