Dynamics

The pinion gear rolls on the gear racks. If b is moving to the right at 6.2 ft/s and c is moving to the left at 3.7 ft/s, determine the magnitude and direction of the angular velocity of the pinion gear

0.3t 0.3 ft

relative to C , B is moving with velocity 6.2-(-3.7)

V_B/C = 9.9 m/s right

Since no slipping is occuring

w*r = V

W_A*0.3 = 9.9

W_A = 33 rad/s anticlockwise
