The truss system supports the hanging beam with distributed

The truss system supports the hanging beam with distributed loading as shown Joint A is a pin connection and joint Eis a roller. 2 oblem #1 With 8 kN/m, which member is seeing the largest Compressive Force and what is its magnitude? Problem #2 With = 8 kN/m, which member is seeing the largest Tension Force and what is its magnitude? Problem #3 If the maximum Tension Force the members of the truss can withstand is 35 kN and the maximum Compressive Force the members of the truss can withstand is 20 kN, calculate the largest (KN/m) the system can support?

Solution
