9 Which type of view is View B a Auxiliary b Aligned c Offse

9. Which type of view is View B? a. Auxiliary b. Aligned c. Offset d. Revolved How many projections (or views) are possible on the cube in Figure D? 10. a. 6 b. 9 C. 3 d. 12 FIGURED

Solution

9) option A is correct. It is Auxillary view. An auxiliary view is an orthographic view which is projected onto any plane other than the frontal, horizontal, or profile plane.

10) Option C is correct. 3 view are possible as the three side are visible for the cube.
