Is this a positively or negatively triggered flip flop?

http://imgur.com/a/ljhHm this is the link for the image not really sure if I uploaded the other one correctly.

Solution

this is a master slave flip flop to avoid race around condtion.

Here master flipflop(1st half) is negatively triggered while slave flip flop(2nd half) is postive triggered one.
