Organize Favorites Desktop Downloads Recent Places SkyD Documents Pictures B Videos Homegroup Computer N Netw ONE56D2B P Do H william henkel Google Chrome Ch https:// www.mathxl.com /Student/Player Homework.aspx?homeworkld 3299973676&que; william henkel 9/12/15 3:10 PM Homework: Chapter 3 homework (Process Overview 3.4 MyOMLab Exercise Score: 0 of 25 pts Assignment Score: 50% (50 of 100 pts) Baker Machine Company is a job shop that Main Menu specializes in precision parts for firms in the Closeness Matrix aerospace industry. The current block plan is as Trips Between Departments Assignments foll Department d grind Do Homewor 2. Numerically controlled equipment 3. Shipping and receiving The wd score for the current layout is 119 4. Lathes and drills 5. Tool crib 6. Inspection Bak uts. Refe trix abo g tv from inspection (6 to shipping and receiving (3) is three units to calculate the weighted distance, wd, scores of the following two block plans to determine which alternative layout i b Alternative layout 1 is as follows The total wd score for alternative 1 is (Enter y k A Clear All Check Answer Save OK Background 12 ber 2015
Two alternate layouts are given. The alternate layout is as follows:
Now let us calculate the wd score where w stands for movement between departments and d stands for rectilinear distance between departments:
Trips (from - to) Distance (d) No. of trips (w) Score wd (w * d)
1----2 1 7 7
1---3 2 12 24
1---5 1 9 9
1----6 1 5 5
2---4 1 3 3
3---5 1 7 7
3---6 1 10 10
4---6 1 3 3
5---6 2 14 28
Total = 96
Therefore, total wd score for alternate is 96
Hence alternate layout is better than the first one having wd score of 119 on the basis of wd scores.
