You will develop the logic for a Bank Alarm System and imple

You will develop the logic for a Bank Alarm System and implement on specified chips. The key lock is active when no one is in the bank, no employees or customers. The Panic button is a switch with multiple locations for employees to activate. The Vault motion sensor is a sensor in the vault to detect motion. The Proximity Sensor is a sensor that senses any vault contact. The Time Sensor is active during off hours. The Time sensor is inactive (unasserted) when the bank is open for customer business. Output Variables A Audible Alarm with Flashing inside and outside lights with police notification S Silent Alarm with Flashing outside lights only with police notification An audible alarm should sound whenever Panic button is active during closed bank hours Key lock is active during closed bank hours and Vault motion sensor is active Proximity Sensor is active during closed bank hours The Silent Alarm should activate when Panic button is active during open bank hours Vault motion sensor is active during closed bank hours and the key lock is inactive

Solution

A = P + K\'V + X

S = P + KV
