For the circuit below, determine :

For the circuit below, determine the power dissipated by the 6 Ohm resistor the voltage across the 4 Ohm resistor the current through the 2 Ohm resistor For the circuit below, determine the power dissipated by the 6 Ohm resistor the voltage across the 3 Ohm resistor the current through the 4 Ohm resistor For the circuit elements below, determine the power generated or absorbed by the element. State whether the power is generated or absorbed.

Solution

1.3)

a) power dissipated by 6 ohm resistor=(18)^2/6=54 watts

b) voltage across 4 ohm resistor=4*1=4 volts

c) current through 2 ohm resistor= 4/2=2 amps

1.4)

a) power dissipated by 6 ohm resistor= (12)^2/6=24 watts

b) voltage across 3 ohm resistor=3*1=3 volts

c) current through 4ohm resistor=4/4=1 amps

1.5)

a) power generated

b) power generated.

c) power absorbed

d) power absorbed.
