Three linear amplifier circuits are connected in cascade and

Three linear amplifier circuits are connected in cascade, and the source and load are connected as shown below. A) Determine the net loaded voltage gain, B) for Vs=20 mV, determine Vo directly using part A). (Note Aso=Vo/Vs)

Took three pics for quality purposes only. PLEASE SHOW WORK AND CIRCUITS

20 ree linear amplifier circuits are co ree linear amplifier circuits are c ad are connected as shown below. 20k R: R, R, A 20 etermine the following a) Net Loaded Voltage Gair b) For v, 20 mV. determi

Solution

Net loaded voltage gain=A1*A2*A3=20*10*4=800
Voltage gain=Vo/Vs=800
Output voltage=800*20*10^-3=16Volts
